BMS Mini Master Module for VCU
The VCU communicates with the BMS via the Mini Master Module and all battery packs need at least one Mini Master unit. The Satellites expand the capability of the Master by an additional 18 cells and 3 thermistors per additional Satellite connected. The Satellite Modules are connected to their Master via a high-speed serial interface (isoSPI) that allows additional units to be daisy chained together, adding as many Satellites as necessary for the battery pack configuration.
The VCU communicates with the BMS via the Mini Master Module and all battery packs need at least one Mini Master unit. The Satellites expand the capability of the Master by an additional 18 cells and 3 thermistors per additional Satellite connected. The Satellite Modules are connected to their Master via a high-speed serial interface (isoSPI) that allows additional units to be daisy chained together, adding as many Satellites as necessary for the battery pack configuration.
- Add-on expansion for VCU products, enabling the VCU’s battery management features
- Distributed BMS architecture allows for easy support of distributed battery packs
- Interfaces with J1772 Charge Port to automatically power up vehicle when charge plug is connected
- Up to 16 BMS18 Satellites can be connected to a single BMS18 Mini Master to support up to 1200V systems
- Communicates with Satellites via a high-speed isolated serial interface (isoSPI)
Information:
NOTE: The Unsealed BMS Satellite must be used with an AEM Vehicle Control Unit (VCU).| Attributes | |
| Brand | AEM |
| Category | Electrical, Charging and Starting |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| Harmonized Tariff Code (Schedule B) | 8507908000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | A |
| part type | EV Battery Thermal Management System (BTMS) Coolant Plate Heat Exchanger Chiller |
| Product Type | BMS Satelite, BMS Satelite |
| SDR Required Flag | N |
| Sub Category | Battery and Related Components, Battery and Related Components |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | 1 Year, Manufacturer's 1 Year Warranty |
| Warranty Time | 12 |
| Wiring Pigtail Included | No, No |
| GTIN | 00810065218643 |
