Low voltage harness assembly designed to be installed in the rear half of the electric vehicle.
This low voltage harness assembly was designed to be installed in the rear half of the electric vehicle. It was designed to be used with a mating front half assembly that is VCU hardware specific. The AEM part number for the mating front half harness is 30-8600.
This low voltage harness assembly was designed to be installed in the rear half of the electric vehicle. It was designed to be used with a mating front half assembly that is VCU hardware specific. The AEM part number for the mating front half harness is 30-8600.
- Connector interface features include:
- Inverter Power (INV PWR)
- J1772 Flying Leads - Proximity Pilot (PROX) and Control Pilot (CP)
- Inline Signals
- Inline CAN
- Power Distribution Unit (PDU)
- Combined Charging Unit (CCU)
- Isabellenhutte (IVTS) - current voltage shunt based measuring system
- - Life Energy Motion (LEM) - current voltage DHAB s/124 Transducer Sensor
- Inverter CAN (INV CAN)
- Inverter High-Voltage Interlock (HVIL)
| Attributes | |
| Brand | AEM |
| Category | Electrical, Lighting and Body |
| Color | Black |
| Country of Origin (Primary) | US |
| Emission Code | 6, 6 |
| Gender | Male Female |
| Harmonized Tariff Code (Schedule B) | 8544300000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| part type | Dash Harness Connector |
| Product Type | Wiring Harness, Wiring Harness |
| SDR Required Flag | N |
| Sub Category | Electrical Connectors |
| Terminal Gender | Male Female |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty Time | 12 |
| GTIN | 00810065217134 |
