1998-2006 GM LS 4L60E (Electronic) 2-Wheel Drive, Manual Shift Valve Body.
The B&M GM 4L60E PreRunner/Trail automatic transmission is for use with Chevrolet LS based engines. This transmission features a manual/forward valve body and includes a deep, cast aluminum pan. Internal components include a beast sunshell, reinforced input drum, "Billet" Corvette 4th gear servo, all new solenoids & wiring harness, 29 element dual cage sprag, all new high performance friction plates, and 8 Count 3-4 Friction Pack with Koleen steels. Max 550 HP / 450 Ft/Lbs. Intended for off road/trail use.
The B&M GM 4L60E PreRunner/Trail automatic transmission is for use with Chevrolet LS based engines. This transmission features a manual/forward valve body and includes a deep, cast aluminum pan. Internal components include a beast sunshell, reinforced input drum, "Billet" Corvette 4th gear servo, all new solenoids & wiring harness, 29 element dual cage sprag, all new high performance friction plates, and 8 Count 3-4 Friction Pack with Koleen steels. Max 550 HP / 450 Ft/Lbs. Intended for off road/trail use.
- Intended for Off-Road Use
- Rated to 550HP and 450 FT/LBS
- Includes Deep Aluminum Pan
- Manual/Forward Valve Body
Information:
For use on LS engines. Does not replace 4L60 (manual shift model). Transmission shipped without speedometer driven gear or housing.Application Summary:
| Year | Make/Model |
|---|---|
| 2000-2006 | Bentley Arnage |
| 1997-2003 | Bentley Azure |
| 2006 | Bentley Azure |
| 1997-1998 | Bentley Brooklands |
| 1997-2003 | Bentley Continental |
| 1997-1998 | Bentley Turbo R |
| 2004-2006 | Buick Rainier |
| 1999-2000 | Cadillac Escalade |
| 2002-2005 | Cadillac Escalade |
| 2003 | Cadillac Escalade ESV |
| 2002-2003 | Cadillac Escalade EXT |
| 1997-2005 | Chevrolet Astro |
| 2002-2006 | Chevrolet Avalanche 1500 |
| 1997-2005 | Chevrolet Blazer |
| 1997-1999 | Chevrolet C1500 |
| 1997-1999 | Chevrolet C1500 Suburban |
| 1997-2000 | Chevrolet C2500 |
| 1997-1999 | Chevrolet C2500 Suburban |
| 1997-2000 | Chevrolet C3500 |
| 1997-2002 | Chevrolet Camaro |
| 2004-2006 | Chevrolet Colorado |
| 1997-2006 | Chevrolet Express 1500 |
| 1997-2006 | Chevrolet Express 2500 |
| 1997-2006 | Chevrolet Express 3500 |
| 1997-1999 | Chevrolet K1500 |
| 1997-1999 | Chevrolet K1500 Suburban |
| 1997-2000 | Chevrolet K2500 |
| 1997-1999 | Chevrolet K2500 Suburban |
| 1997-2000 | Chevrolet K3500 |
| 1997-1999 | Chevrolet P30 |
| 1997-2004 | Chevrolet S10 |
| 1999-2006 | Chevrolet Silverado 1500 |
| 2001-2003 | Chevrolet Silverado 1500 HD |
| 2005-2006 | Chevrolet Silverado 1500 HD |
| 1999-2004 | Chevrolet Silverado 2500 |
| 2001-2006 | Chevrolet Silverado 2500 HD |
| 2001-2006 | Chevrolet Silverado 3500 |
| 2003-2004 | Chevrolet SSR |
| 2000-2006 | Chevrolet Suburban 1500 |
| 2000-2006 | Chevrolet Suburban 2500 |
| 1997-2006 | Chevrolet Tahoe |
| 2002-2006 | Chevrolet Trailblazer |
| 2002-2006 | Chevrolet Trailblazer EXT |
| 1997-1999 | GMC C1500 |
| 1997-1999 | GMC C1500 Suburban |
| 1997-2000 | GMC C2500 |
| 1997-1999 | GMC C2500 Suburban |
| 1997-2000 | GMC C3500 |
| 2004-2006 | GMC Canyon |
| 2002-2006 | GMC Envoy |
| 2002-2006 | GMC Envoy XL |
| 2004-2005 | GMC Envoy XUV |
| 1997-2005 | GMC Jimmy |
| 1997-1999 | GMC K1500 |
| 1997-1999 | GMC K1500 Suburban |
| 1997-2000 | GMC K2500 |
| 1997-1999 | GMC K2500 Suburban |
| 1997-2000 | GMC K3500 |
| 1997-2005 | GMC Safari |
| 1997-2006 | GMC Savana 1500 |
| 1997-2006 | GMC Savana 2500 |
| 1997-2006 | GMC Savana 3500 |
| 1999-2006 | GMC Sierra 1500 |
| 2001-2003 | GMC Sierra 1500 HD |
| 2005-2006 | GMC Sierra 1500 HD |
| 1999-2004 | GMC Sierra 2500 |
| 2001-2006 | GMC Sierra 2500 HD |
| 2001-2006 | GMC Sierra 3500 |
| 1997-2004 | GMC Sonoma |
| Attributes | |
| 2WD/4WD | 2WD, 2WD |
| Automotive Item Grade | High Performance, High Performance |
| Brake Included | No |
| Brand | B&M, B&M |
| Built-In Transmission Shield | No, No |
| Bullet Point #1 | Manual/Forward Valve Body |
| Bullet Point #2 | Includes Deep Aluminum Pan |
| Bullet Point #3 | Intended for Off-Road Use |
| Bullet Point #4 | Rated to 550HP and 450 FT/LBS |
| California Proposition 65 | Yes |
| Case Material | Cast Aluminum, Cast Aluminum |
| Category | Transmission |
| Color | Black, Black |
| Control Type | Electronic, Electronic |
| Cooler included | No, No |
| Core Change Applicable | No, No |
| Country of Origin (Primary) | US |
| Dipstick Included | No, No |
| Drive Type | RWD, RWD |
| Emission Code | 5, 5 |
| Friction Plate | New |
| Friction Plates | New, New |
| Friction Plates: | New |
| Gear Ratio-First | 3.06, 3.06 |
| Gear Ratio-Fourth | 0.7, 0.70 |
| Gear Ratio-Second | 1.63, 1.63 |
| Gear Ratio-Third | 1, 1.00 |
| Harmonized Tariff Code (Schedule B) | 8708401110 |
| Hazardous Material Code | N |
| Horsepower Rating (HP) | 550 |
| Horsepower Rating | 550 |
| Horsepower Rating (HP) | 550, 550 |
| Intermediate and Low Roller Clutches | New |
| Intermediate&Low Roller Clutches: | New |
| Life Cycle Status Code | Available to Order |
| Manual Valve Body | Yes |
| NAFTA Preference Criterion Code | B |
| Package Contents | Transmission |
| part type | High Performance |
| Product Type | Automatic Transmission Assembly, Transmission |
| Reverse Gear Ratio | 2.29, 2.29 |
| Reverse Pattern | No |
| SDR Required Flag | N |
| SDS Sheet Number | N |
| Standard Pack | 1 |
| Sub Category | Automatic Transmission Components, Automatic Transmission Components |
| Torque Capacity | 450 ft/lbs. |
| Torque Converter Included | No, No |
| Torque Rating (Ft/Lbs) | 450, 450 |
| Trans Model | GM- 4L60E (Auto) 4 Speed |
| Transbrake | No, No |
| Transmission Model | 4L60E, 4L60E |
| Transmission Pan Finish | Natural, Natural |
| Transmission Pan Material | Aluminum, Aluminum |
| Transmission Pan Type | Deep Cast, Deep, Cast |
| Transmission Series | Prerunner/Trail, Full Race |
| Transmission Speeds | 4, 4 |
| Transmission Type | 4L60E, Automatic |
| Valve Body Configuration | Recalibrated |
| Valve Body Pattern | Forward, Forward |
| Valve Body Type | Manual, Manual |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty Time | 3 |
