Machined to Mount Directly Under the ReMaster Master Cylinder
The Remaster specific adjustable proportioning valve is machined to mount directly under the Remaster for a clean, compact unit. The ReMaster valve is available in both left and right port configuration with in/out ports for the rear which the valve controls as well as a pass through for the front to make plumbing simple and clean. Just like the ReMaster master cylinder, this valve offers removable seats, and can be used with inverted flare fittings or straight banjo fittings. The valve includes 4) brass seats and 4) 3/8” x 24 tube nuts. Available in black, gray, or polished finishes and left or right port configuration to match the ReMaster.
- Includes tube nuts and brass seats
- 3/8-24 Thread, IFF w/included seats, Straight (Banjo) w/o seats
- Integrated mounting block for easy installation beneath ReMaster Master Cylinders.
- Made in the USA
- Laser etched body
Application Summary:
| Year |
Make/Model |
| ReMaster |
- 3/8 in-24 Polished Anodized Left-Port Proportioning Valve with Integrated Mount, Fittings, and Hardware |
| Attributes |
| Adjustment Style |
Knob |
| Bleeder Hoses Included |
No |
| Bleeder Screw Included |
No |
| Box Count |
1, 1 |
| Brake Booster Included |
No |
| Brake Pressure Switch(s) Included |
No |
| Brand |
Baer Brakes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Brake |
| Color |
Polished |
| Connector For Warning Light |
No, No |
| Country of Origin (Primary) |
US |
| Emission Code |
6, 6 |
| Export Description |
Brake Components, Brake Components |
| Finish |
Polished, Polished |
| Fittings Included |
Yes, Yes |
| Grade Type |
Premium, Premium |
| Harmonized Tariff Code (Schedule B) |
8708.30.50 |
| Hazardous Material Code |
N |
| Includes |
1x Proportioning Valve, 4x Tube Nuts, 2x Mounting Bolts, 1x Proportioning Valve, 4x Tube Nuts, 2x Mounting Bolts |
| Inlet Fitting |
3/16" Inverted Flare w/ Brass Seat, 3/8” x 24 Tube Nuts |
| Inlet Port Inside Diameter |
3/8 |
| Inlet Port Quantity |
2 |
| Inlet Port Size |
3/8-24, 3/8-24 |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum |
| Mounting Block Included |
Integrated, Integrated |
| Mounting Hardware Included |
Yes |
| Mounting Hole Quantity |
2 |
| NAFTA Preference Criterion Code |
A |
| Outlet Fitting |
3/16" Inverted Flare w/ Brass Seat, Banjo w/o Brass Seat |
| Outlet Port Inside Diameter |
3/8 |
| Outlet Port Quantity |
2 |
| Outlet Port Size |
3/8-24, 3/8-24 |
| part type |
Brake Proportioning Valve |
| Port Exit |
Left Side, Left Side |
| Product Line |
Proportioning Valve w/ Integrated Mount, Proportioning Valve w/ Integrated Mount |
| Quantity |
Sold Individually, Sold Individually |
| Removable Seats |
Yes, Yes |
| SDR Required Flag |
N |
| Series |
Remaster, Remaster |
| Sub Category |
Valves |
| System Notes |
polished,left port, polished,left port |
| Universal Or Specific Fit |
Specifically for use with Remaster Master Cylinders, Specifically for use with Remaster Master Cylinders |
| Valve Type |
Adjustable, Adjustable |
| Warning |
California Proposition 65 |
| Warranty Time |
1 |
| Weight |
2, 2 |
| GTIN |
00844165052005 |
