Baer Brakes Remaster Master Cylinder: A small, compact, 1-piece body machined out of 6061 T6 billet aluminum, 1-1/8 in. Bore, Left Side Ports, Black Anodized, with a 2-bolt mounting flange fitting many Ford and GM applications.
This Remaster master cylinder features a small, compact, 1-piece body machined out of 6061 T6 billet aluminum with a 1-1/8" bore, left side ports and a 2-bolt mounting flange fitting many Ford and GM applications. The billet top is attached with 6 allen screws and has two large billet aluminum, knurled screw-on caps making for easy filling without spillage. The unique outlet port design allows for either inverted flare (w/included removable seats) or banjo style, straight fittings. The Remaster is compatible on most long and short, w/included bullet, boosters or manual brake applications. Optional proportioning valves also available
- 2-Bolt GM/Ford Firewall Mounting Bracket
- Fully machined 6061 T6 billet aluminum construction
- Unique 3/8-24 outlet port design allows for either inverted flare (w/included removable seats), banjo style or straight fittings.
- Left Side Ports
- Machined and knurled screw-on caps for easy access to fill without spillage
- Anodized Remasters feature laser-etched logos
Information:
Ships in 1 Box
Application Summary:
| Year |
Make/Model |
| ReMaster |
2-Bolt GM/Ford Master Cyl Assembly, black anodized, 1-1/8in. bore, left port. Please note, some long push-rod hydro-boost and vacuum boosters may require an additional spacer, p/n 6260258, to space the Remaster away from the booster push-rod. |
| Attributes |
| Area |
0.97 |
| Bleeder Hoses Included |
No |
| Bleeder Screw Included |
No |
| Bore Size |
1.125, 1-1/8 |
| Box Count |
1, 1 |
| Brake Booster Included |
No |
| Brand |
Baer Brakes, Baer Brakes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Brake |
| Connector For Warning Light |
No, No |
| Country of Origin (Primary) |
US |
| Emission Code |
6, 6 |
| Export Description |
Brake Components, Brake Components |
| Fittings Included |
Yes, Yes |
| Flange Type |
2 Bolt GM/Ford, 2 Bolt GM/Ford |
| Gasket Or Seal Included |
No |
| Grade Type |
Premium, Premium |
| Harmonized Tariff Code (Schedule B) |
8708.30.50 |
| Hazardous Material Code |
N |
| Includes |
1x Master Cylinder Assembly, 2 Brass Seats, 2 Tube Nuts, 1x Master Cylinder Assembly, 2 Brass Seats, 2 Tube Nuts |
| Life Cycle Status Code |
Available to Order |
| Master Cylinder Bore Diameter |
1-1/8 |
| Master Cylinder Cap Included |
Yes |
| Master Cylinder Material |
6061 T6 billet aluminum |
| Master Cylinder Outlet Port Fittings |
3/16" Inverted Flare w/ Brass Seat, Banjo w/o Brass Seat |
| Master Cylinder Outlet Port Quantity |
2, 2 |
| Master Cylinder Outlet Port Size |
3/8-24, 3/8-24 |
| Master Cylinder Port Exit |
Left side, Left side |
| Mounting Hardware Included |
No |
| Mounting Hole Quantity |
2 holes |
| NAFTA Preference Criterion Code |
A |
| part type |
Brake Master Cylinder |
| Product Line |
Master Cylinder Assembly, Master Cylinder Assembly |
| Proportioning Inlet Port Size |
3/8-24 |
| Proportioning Mounting Block Included |
Sold Separately |
| Proportioning Outlet Port Size |
3/8-24 |
| Quantity |
Sold Individually, Sold Individually |
| Remaster Body Color |
Black, Black |
| Remaster Body Finish |
Anodized, Black Hard Anodized |
| Remaster Caps Color |
Black, Black |
| Remaster Caps Finish |
Anodized, Black Hard Anodized |
| Remaster lid Color |
Black, Black |
| Remaster lid Finish |
Anodized, Black Hard Anodized |
| Removable Seats |
Yes, Yes |
| Reservoir Included |
Yes |
| Reservoir Material |
6061 T6 billet aluminum |
| Reservoir Size |
7oz per reservoir, Fill to 75% or 5.25oz per reservoir, 7oz per reservoir, Fill to 75% or 5.25oz per reservoir |
| Reservoir Type |
Dual |
| Sale Category |
Brakes |
| SDR Required Flag |
N |
| Sensor Included |
No |
| Series |
ReMaster, ReMaster |
| Stroke |
1.3, 1.3 |
| Sub Category |
Brake Hydraulics |
| System Notes |
black anodized,1-1/8IN bore,left port, black anodized,1-1/8IN bore,left port |
| Universal Or Specific Fit |
Universal, Specific Fit |
| Volume Ratio |
2:1 , 2:1 |
| Warning |
California Proposition 65 |
| Warranty Time |
1 |
| GTIN |
00844165051220 |
