KTM XL40 (A/C) Headlight Kit - KTM 2013-16 200 XC-W/250 SX/250 XC/250 XC-W/300 XC/300 XC-W
Upgrade your off-road lighting with the Baja Designs XL40 (A/C) LED Headlight Kit - purpose-built for 2013-2016 KTM XC, XC-W, and SX models. This kit includes a regulator/rectifier that converts your bike's A/C power to D/C, enabling fast, plug-and-play installation with the stock harness. Inspired by the performance of the XL80, the XL40 delivers 5,224 lumens of trail-proven illumination to a wider range of bikes. Engineered for dirt bikes with lower-output OEM stators, it draws just 43.5W - a powerful upgrade without the large power draw.
- This kit includes a regulator/rectifier that converts your bike's A/C power to D/C, enabling fast, plug-and-play installation with the stock harness
- Inspired by the performance of the XL80, the XL40 delivers 5,224 lumens of trail-proven illumination to a wider range of bikes
- Engineered for dirt bikes with lower-output OEM stators, it draws just 43
Information:
Headlight Kit
Application Summary:
| Year |
Make/Model |
| KTM |
200-300 XC-W/SX/XC ('13-16) |
| Attributes |
| Amperage Rating (A) |
3.4 |
| Average Rated Life (hr.) |
49930 |
| Beam pattern |
Trail |
| Bezel Material |
Powder Coated Cast Aluminum |
| Brightness (Lumens) |
5,224 (Hi) / 1,435 (Low) |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
US |
| Depth (in.) |
3.65 |
| DES |
XL40 (A/C) LED Headlight Kit |
| Description |
Trail; Clear |
| Effective Lighting Score (ELS) |
High: 92°/5.9/226’/5224; Low: 74°/5.9/119’/1435 |
| EXT |
KTM XL40 (A/C) Headlight Kit - KTM 2013-16 200 XC-W/250 SX/250 XC/250 XC-W/300 XC/300 XC-W |
| Hazardous Material Code |
N |
| Height (in.) |
4.43 |
| Housing Color |
Black |
| Housing Material |
Powder Coated Cast Aluminum |
| Length (in.) |
4.43 |
| Lens Color |
Clear |
| Lens Material |
Hardcoated Polycarbonate |
| Life Cycle Status Code |
Available to Order |
| Light Quantity |
1 |
| Lighting Modes |
Beam |
| Lighting Quantity |
4 |
| Lighting Technology |
LED |
| Lighting Type |
Forward Projecting |
| Mounting Hardware Included |
Yes |
| Mounting Hardware Material |
Stainless Steel |
| NAFTA Preference Criterion Code |
B |
| Overvoltage Protection |
Built-In |
| Product Type |
XL40 |
| SDR Required Flag |
N |
| Standards/Compliance (Durability) |
Exceeds MIL-STD810G (Mil-Spec Testing) |
| Standards/Compliance (Impact Resistance) |
IK10 Compliant (Mechanical Impact Testing) |
| Standards/Compliance (Water Resistance) |
IP69K (Waterproof up to 9ft & Pressure Washable) |
| TLE |
KTM XL40 (A/C) Headlight Kit - KTM 2013-16 200 XC-W/250 SX/250 XC/250 XC-W/300 XC/300 XC-W |
| Universal or Specific |
Universal |
| Wattage (W) |
43.5 |
| Weight (lbs.) |
2.45 |
| Wiring Harness Included |
No |
| GTIN |
00810160464624 |
