Centerforce(R) DFX Clutch Discs are paddle style discs using ceramic materials for more aggressive engagement. These discs are replacements for Centerforce DFX pressure plates.
Centerforce(R) brings together high-quality friction materials and patented processes to give you top-of-the-line discs. Centerforce offers discs for the Centerforce I, Centerforce II, Dual Friction, LMC, and DFX series clutches. Each disc is designed to work best with a corresponding Centerforce pressure plate. DFX Discs are stronger paddle style discs using ceramic materials for more aggressive engagement. These discs are replacements for Centerforce DFX pressure plates.
Application Summary:
| Year |
Make/Model |
| 1993-1997 |
Chevrolet Camaro |
| 1989-1996 |
Chevrolet Corvette |
| 1993-1997 |
Pontiac Firebird |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
11.000, 11, 11.000, 279.4 |
| Country of Origin (Primary) |
MX |
| Disc Material |
Cerametallic, Cerametallic, Cerametallic |
| Disc Type |
6-Paddle, 6-Paddle, 6-Paddle |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-1/8, 1-1/8, 1-1/8 |
| Input Spline Quantity |
26, 26, 26 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cerametallic Button Style Friction, Cerametallic Button Style Friction, Cerametallic Button Style Friction |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
4.40, 4.40 |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
Y, Y, Y |
| Warranty Time |
12 |
| GTIN |
00788442033380 |
