The Centerforce(R) I Clutch Series is designed as a high-quality stock replacement for applications with stock engines or mild power increases from minor bolt-on modifications.
The Centerforce(R) I Clutch Series utilizes a full facing disc with premium friction material and is designed as a high-quality entry-level performance clutch for those in need of a superior stock replacement. Using the Centerforce centrifugal weights (where applicable), the Centerforce Stage 1 clutch system is perfect for applications with stock engines or mild power increases from minor bolt-on modifications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce I Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.
Application Summary:
| Year |
Make/Model |
| 1978-1980 |
Ford Bronco |
| 1977-1980 |
Ford F-150 |
| 1977-1980 |
Ford F-250 |
| 1977-1980 |
Ford F-350 |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B00T1X2AW8 |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
3, 3 |
| Clutch Bolt Size |
3/8 - 16 X 0.900, 0.900 x 3/8 x 16, 3/8 - 16 X 0.900 |
| Clutch Bolt Type |
Shouldered, Shouldered, Shouldered |
| Clutch Disc Diameter |
11, 11, 279.4 |
| Counterweight Assist |
YES, Yes |
| Country of Origin (Primary) |
KR |
| Disc Material |
Organic, Organic |
| Disc Type |
Full face, Full face |
| Disc Type Sprung Solid |
Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Deck Height |
2.090, 2.09 |
| Flywheel Step Type |
Flat, Flat, Flat |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, T.O.B., BOLTS, Alignment Tool. |
| Input Shaft Diameter |
1-1/16, 1-1/16 |
| Input Spline Quantity |
10, 10 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Nodular Iron Pressure Plate / Organic Friction, Nodular Iron Pressure Plate / Organic Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface (Standard) |
11 |
| Release Bearing Included |
Yes, Yes |
| Replaceable Friction Surface |
N |
| SDR Required Flag |
N |
| Spline Diameter and Tooth Count |
1-1/16"-10 |
| Standard Pack |
1 |
| Torque Capacity |
522, 522, 522 |
| Warranty Time |
12 |
| GTIN |
00788442028676 |
