RPM ACTIVATED SWITCH
The Dedenbear RPM2 RPM Activated switch allows you to trigger a wide variety of electrical devices on your race vehicle based on a pre-selected, user-defined RPM point with incredible repeatability. Push button controls eliminate the need for separate pills or modules and built in design features such as manual override, time delay, and disable circuit make this module ideally suited for control of an air or electric solenoid control shifter. Suitable for use with 8 cylinder applications. Magneto compatible with purchase signal converter such as AutoMeter #9118.
The Dedenbear RPM2 RPM Activated switch allows you to trigger a wide variety of electrical devices on your race vehicle based on a pre-selected, user-defined RPM point with incredible repeatability. Push button controls eliminate the need for separate pills or modules and built in design features such as manual override, time delay, and disable circuit make this module ideally suited for control of an air or electric solenoid control shifter. Suitable for use with 8 cylinder applications. Magneto compatible with purchase signal converter such as AutoMeter #9118.
- Rated Up To 10A
- Built In .5 Second Delay
- Normally Open And Normally Closed Output Terminals
- Configured For 8 Cylinder 4 Pulse/Revolution Tach Output Signals
- 12 And 16V Compatible
- Manual Upshift Trigger Button; Allows Driver Override And Testing
- Built In Time Delay Prevents False Shifts Off Line
- Disable Circuit Prevents Shifting During Burnouts
| Attributes | |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| Emission Code | Legal US |
| Gauge Size | 134mm x 108mm x 32mm, 5.250 in. x 4.250 in. x 1.250 in. |
| Harmonized Tariff Code (Schedule B) | 9029900000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Mounting Hardware Included | Yes |
| NAFTA Preference Criterion Code | B |
| SDR Required Flag | N |
| Voltage | 8-18 V |
| Warranty Time | 12 |
| GTIN | 00046074164699 |
