SHIFT TIMER/SINGLE STAGE TIMER; N.O. OR N.C. OUTPUT
The Dedenbear ST1 is a single stage timer that can be used to activate a device such as a shifter, throttle stop, nitrous solenoid, or timing retard based on time rather than RPM. The Shift Timer works particularly well in cars that have 'loose' converters. The engine in a car with a 'loose' converter tends to run at a fixed RPM until the converter locks up and stops slipping. Since the engine runs in a narrow RPM band near the intended shift point for a large portion of the run, the actual shift point can vary widely. The ST1 will allow the car to shift at a precise point during a run and the engine RPM doesn't matter.
The Dedenbear ST1 is a single stage timer that can be used to activate a device such as a shifter, throttle stop, nitrous solenoid, or timing retard based on time rather than RPM. The Shift Timer works particularly well in cars that have 'loose' converters. The engine in a car with a 'loose' converter tends to run at a fixed RPM until the converter locks up and stops slipping. Since the engine runs in a narrow RPM band near the intended shift point for a large portion of the run, the actual shift point can vary widely. The ST1 will allow the car to shift at a precise point during a run and the engine RPM doesn't matter.
- Adjustable Timer 0-9.99 Sec. Programmed w/Push Button Thumbwheels
- Selectable Output Of .05 Second Pulse For Applications
- Like Shifter Activation Long 17 Second Pulse For Applications
- Output Terminals Normally Closed/Open To Either Apply/Remove 12V
- Release Of The Trans Brake Or Line Lock Solenoid Starts The timer
| Attributes | |
| ASIN | B01M4PE5VA |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| Emission Code | Legal US |
| Gauge Size | 165mm x 86mm x 32mm, 6.500 in. x 3.380 in. x 1.250 in. |
| Harmonized Tariff Code (Schedule B) | 9032896085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Mounting Hardware Included | Yes |
| NAFTA Preference Criterion Code | B |
| SDR Required Flag | N |
| Trans Model | N/A |
| Voltage | 8-18 V |
| Warranty Time | 12 |
| GTIN | 00046074165023 |
