Adjustable billet by-pass return style fuel pressure regulator 3/8" NPT
Boost Reference - 1:1
Holley Billet Fuel Pressure Regulators are part of a complete line of fuel system products from Holley. They are precision machined from 6061-T6 billet aluminum for strength and durability. These regulators are adjustable from 4-65 psi and will handle both carbureted and EFI applications. A second pressure spring is included allowing you to increase the fuel pressure range up to 65 psi for EFI systems. They are offered with two port sizes, 3/8" NPT or 6AN to adapt to your new or existing fuel lines. So, if you are currently running a carbureted system but plan to upgrade to EFI in the future, these regulators will have you covered either way.
Holley Billet Fuel Pressure Regulators are part of a complete line of fuel system products from Holley. They are precision machined from 6061-T6 billet aluminum for strength and durability. These regulators are adjustable from 4-65 psi and will handle both carbureted and EFI applications. A second pressure spring is included allowing you to increase the fuel pressure range up to 65 psi for EFI systems. They are offered with two port sizes, 3/8" NPT or 6AN to adapt to your new or existing fuel lines. So, if you are currently running a carbureted system but plan to upgrade to EFI in the future, these regulators will have you covered either way.
- Adjustable from 4-65 psi for precise fuel pressure adjustments
- Constructed of billet aluminum with a black anodized base and a clear anodized top for good looks
- Used in systems with a return line back to the tank
- (1) 3/8” NPT Inlet; (1) 3/8” NPT Outlet; and (1) 3/8” NPT Return Port
- Includes fitting for manifold reference
- Includes an 1/8 NPT gauge port
- Boost Reference - 1:1
- The 4-15 psi carbureted spring comes installed in the regulator
- Compatible with diesel fuel and E85
| Attributes | |
| Adjustable | Yes |
| ASIN | B01JP2IT3S |
| Brand | Holley, Holley |
| California Proposition 65 | No |
| Category | Air and Fuel Delivery |
| Color | Black, Black |
| Country of Origin (Primary) | US |
| Emission Code | 5, 3 |
| Fuel System | EFI/Carb, EFI/Carb |
| Fuel System Type | EFI/Carb |
| Fuel Type | Gasoline / Diesel / E85, Gasoline |
| Gauge Port | Yes, Yes |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8413301000 |
| Hazardous Material Code | N |
| Inlet Port Diameter | 3/8, 3/8 |
| Inlet Quantity | 1, 1 |
| Inlet Size | 0.375 in. NPT, 3/8 inch NPT |
| Inlet Type | NPT |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum, Aluminum |
| Mounting Hardware Included | Yes, Yes |
| Mounting Type | Inline |
| NAFTA Preference Criterion Code | B |
| Outlet Port Diameter | 3/8, 3/8 |
| Outlet Quantity | 1, 1 |
| Outlet Size | 0.375 in. NPT, 3/8 inch NPT |
| Outlet Type | NPT |
| part type | Fuel Pressure Regulator |
| Port Quantity | 3 |
| Pressure | 4-65 PSI |
| Product Type | Regulator, Fuel Pressure Regulator |
| Return Size | 0.375 in. NPT, 3/8 inch NPT |
| Sale Category | Air and Fuel Delivery |
| SDR Required Flag | N |
| Style | Bypass, Bypass |
| Sub Category | Carburetion |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00090127734971 |
