Universal floatless laser fuel level sender
Max operating temperature of 185 degrees
Max operating temperature of 185 degrees
- Improved design with flying leads for easy wiring and prevents accidental contact with surfaces above sending unit
- Quickly reads fuel levels with zero contact
- Easy installation with no moving parts - popular 5 bolt flange
- Long life sensor and no failing floats
- Easy to program the level of any tank and electronic gauge - does not work with OE style gauges that utilize an ohm only input
- Bolt Circle Diameter (BCD) is 2.122"
- Output is a PWM signal for 12 Volt applications (10 volts to 20 volts maximum)
- Includes mounting hardware and rubber gasket
- May not work on Highly Reflective Stainless-Steel Tanks
Information:
The Holley Easy Level(TM) uses LiDAR Technology, It should be installed on the flat top horizontal surface of the tank.| Attributes | |
| # Bolt Holes | 5 |
| Application | Universal |
| Bolt Hole Quantity | 5 |
| Brand | Holley |
| Category | Air and Fuel Delivery |
| Country of Origin (Primary) | CN |
| Emission Code | 6, 6 |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 9026106000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Material | Plastic, Plastic |
| part type | Fuel Level Sensor |
| Product Type | Fuel Gauge Level Sender, Fuel Gauge Level Sender |
| Sale Category | Air and Fuel Delivery |
| SDR Required Flag | N |
| Sub Category | Sensors |
| Warning | California Proposition 65, California Proposition 65 |
| GTIN | 00090127849057 |
