Everything you need to connect a 6-Bolt LS Engine to a Tremec T-56 or Magnum Transmission
The 319-511 is very similar to the 319-510 but is designed to be used with the 8-bolt flywheel LS and Gen V LT engines that come after 2009 (LSA, LT1, LT4, L83, and similar truck engines).
The 319-511 is very similar to the 319-510 but is designed to be used with the 8-bolt flywheel LS and Gen V LT engines that come after 2009 (LSA, LT1, LT4, L83, and similar truck engines).
- Designed for Gen III/Gen IV Small Block Chevrolet Engines with 6-bolt crank/flywheel using a GM-style Tremec T-56 or Magnum Transmission
- Light weight cast aluminum bellhousing and stamped steel dust cover provides factory-like installation and appearance
- Billet steel flywheel for light weight (28 pounds) and additional strength
- Roller style pilot bearing offers improved shifting by reducing parasitic drag and transmission wear
- 26-spline, 12-inch organic sprung clutch offers superior clamping force and smooth engagement for engines up to 550 Naturally Aspirated Horsepower (500 w/ Power Adder)
- Adjustable Hydraulic Release Bearing offers reduced pedal effort and easy installation
- Works with OE (original equipment) or MSD High Torque starters
- All hardware included (flywheel, transmission, and engine connections)
| Attributes | |
| Bellhousing Material | Aluminum |
| Brand | Holley |
| Category | Transmission |
| Country of Origin (Primary) | US |
| Crankshaft Bolt Hole Count | 6, 6 |
| Disc Diameter | 12, 12 |
| Disc Material | Organic, Organic |
| Disc Style | Spring Hub, Spring Hub |
| Emission Code | 5, 5 |
| Engine | GM Gen III/IV (LS), GM Gen III/IV (LS) |
| Engine Make | GM, GM |
| Flywheel Material | Billet Steel, Billet Steel |
| Grade Type | Performance |
| Hardware | Steel, Steel |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Input Shaft Diameter | 1-1/8 in., 1-1/8 in. |
| Input Spline | 26, 26 |
| Life Cycle Status Code | Available to Order |
| part type | Transmission Installation Kit |
| PILOT BEARING | Roller, Roller |
| Pressure Plate Style | Diaphragm, Diaphragm |
| Product Type | Installation Kit, Installation Kit |
| RELEASE BEARING | Hydraulic, Hydraulic |
| Sale Category | Transmission and Drivetrain |
| SDR Required Flag | N |
| Sub Category | Manual Transmission Components |
| Transmission | T56 GM, T56 Magnum GM, T56 GM |
| Warning | California Proposition 65, California Proposition 65 |
| GTIN | 00090127475263 |
