SES Intercooler Pipes, Part No. SES1573ICPBLK, 2016-2021 Honda Civic L4-1.5L Turbo, 2017-2020 Honda Civic Si L4-1.5L Turbo.
Injen Intercooler pipes are the next logical step in your search for power gains. The Injen staff has put in the time and work to develop parts that perform. These Intercooler pipes are no different, after investigating the OE piping, our engineers identified numerous areas where improvement was necessary. The Injen performance intercooler pipes are constructed of mandrel-bent aluminum piping that eliminates the rust buildup present in the most stock pipes. Injen's Automotive Grade Silicone Couplers and Stainless Steel Band Clamp with Inner Protective Liner are also included in this kit. The Injen technology Silicone Couplers are on a new level. Compared to normal silicone, Injen Automotive Grade Silicone Couplers provide superior resistance to heat, pressure, fuel, and oil. This effectively increases the life of the couplers by preventing leaks and blowouts. The Injen Intercooler Pipe Kit is designed to work with the stock as well as the Injen performance intercooler. This Intercooler pipe performance kit, like all of our Injen performance parts, includes the Injen Limited Lifetime Warranty.
- Manufactured from 2.25"Lightweight 6061-T6 Aluminum Piping
- Increase Throttle Response and Decreases Turbo Lag
- Beaded Tube Ends to Help Prevent Couplers from Coming Off
- Mandrel-bent Tubing for Increased Flow
- Uses all factory mounting locations Includes all necessary hardware for a hassle-free installation
- Made in Pomona, California USA
- Injen Technology Limited Lifetime Warranty
- This product is not CARB exempt at this time and is not legal for sale in California or use on vehicles registered with the California Department of Motor Vehicles.
- Intercooler not included
- Optional front mount intercooler P/N# FM1573i
- Hot and Cold side pipes included
- Precision CNC machined, and TIG-Welded sensor flanges included
- Available in 3 amazing colors for that personal touch
- Stainless Steel Band Clamp with Inner Protective Liner
- Automotive Grade Silicone Couplers
- Unique Injen Logo Plate for a Refined Style
Information:
No intercooler included. Optional front mount intercooler available part # FM1573i
Application Summary:
| Year |
Make/Model |
| 2016-2021 |
Honda Civic |
| Attributes |
| Attachment Method |
Flange and Silicone, Flange and Silicone |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CNC Flanges Included |
Yes, Yes |
| CNC Sensor Adapters Inlcuded |
Yes, Yes |
| Compatible Throttle Controller |
PT0018B, PT0018B |
| Country of Origin (Primary) |
US |
| Emission Code |
Not in CA |
| Finish |
Black, Black |
| Grade Type |
Performance, Performance |
| Hardware Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8409914000 |
| Hazardous Material Code |
N |
| Hot and Cold Side Included |
Yes, Yes |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Pipe Material |
6061-T6 Aluminum, 6061-T6 Aluminum |
| Pipe Size |
2.25, 2.25 |
| SDR Required Flag |
N |
| Stepped Design |
No, No |
| GTIN |
00843115022549 |
