Single Exit High Tuck Exhaust System, Part No. SES5007, 2020 Jeep Gladiator JT V6-3.6L.
Don't hesitate and order your new exhaust system today!
- Injen's legendary Single exit, high-tuck, cat-back design
- Show Quality Embossed Stainless Steel Muffler
- Unique Muffler Designed Specifically for the Jeep JK/JL/JT
- Premium Stainless Steel Hardware and Hangers
- Designed and Made in Pomona, CA
- Exhaust exits at the OE location for endless bumper and suspension options
- Dyno Proven gains of up to 5 hp and 5 lb-ft. of torque
- Full 76MM piping made from premium 304 SS Mandrel-Bent Tubing
- Features Injen's low-profile oval muffler to deliver a clean, crisp, distinctively Injen sound
- No Cutting or Welding Required
- If you're looking to improve sound, power, and looks then this is the system for you!
- Pairs perfectly with our cold air intake EVO5005 and EVO5005C
- Hand Crafted and TIG Welded to Perfection for Strength and Durability
Application Summary:
| Year |
Make/Model |
| 2020-2023 |
Jeep Gladiator |
| Attributes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Compatible Throttle Controller |
PT0010B, PT0010B |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Exhaust System Connection |
Clamp, Clamp |
| Exhaust Type |
Cat-Back |
| Exit Position |
Single |
| Finish |
Polished, Polished |
| Grade Type |
Performance, Performance |
| Hangers Included |
Yes, Yes |
| Hardware Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708920000 |
| Hazardous Material Code |
N |
| Inlet Inside Diameter |
3.000 in. |
| Life Cycle Status Code |
Available to Order |
| Material |
304 Stainless Steel |
| Muffler Body Diameter |
4.5X11.0, 4.5X11.0 |
| Muffler Body Length |
11, 11 |
| Muffler Body Material |
304 Stainless Steel, 304 Stainless Steel |
| Muffler Body Shape |
Oval, Oval |
| Muffler Flanged Inlet |
No, No |
| Muffler Flanged Outlet |
No, No |
| Muffler Let Size |
3, 3 |
| Muffler Outlet Quantity |
1, 1 |
| Muffler Outlet Size |
3, 3 |
| Muffler Quantity |
1, 1 |
| NAFTA Preference Criterion Code |
B |
| Pipe Material |
304 Stainless Steel, 304 Stainless Steel |
| Primary Pipe OD |
3, 3 |
| SDR Required Flag |
N |
| Secondary Pipe OD |
3, 3 |
| Stepped Pipe Diameter |
No, No |
| Tail Pipe Diameter |
3.000 in. |
| Tail Pipe Material |
Stainless Steel, Stainless Steel |
| Tail Pipe Outlet Outside Diameter |
3, 3 |
| Tail Pipe Quantity |
1, 1 |
| Tubing Diameter |
3.000 in. |
| Y-Pipe Included |
No, No |
| GTIN |
00843115027520 |
