High output distributorless ignition. 2, 3 or 4-coil pack.
For full bred drag race engines running high boost pressures from turbos, blowers or nitrous we offer a Higher Output version of the DIS Ignition Control. The DIS-4 Plus HO Ignition produces an incredible 170 millijoules of spark energy with 470 primary volts. This increased output will light up fuel mixtures even under extreme cylinder pressures.
For full bred drag race engines running high boost pressures from turbos, blowers or nitrous we offer a Higher Output version of the DIS Ignition Control. The DIS-4 Plus HO Ignition produces an incredible 170 millijoules of spark energy with 470 primary volts. This increased output will light up fuel mixtures even under extreme cylinder pressures.
- Two adjustable Rev Limits
- 10-18 Volts, Negative Ground
- Adjustable retard stage
- Ignition Interrupt Circuit
- Diagnostic LED
- 14,000 RPM with 14.4 Volts
- 10 Amps at 10,000 RPM
| Attributes | |
| ASIN | B000COOK64 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Black |
| Connector Gender | Male |
| Connector Quantity | 1 |
| Country of Origin (Primary) | US |
| Current Draw | 10 Amp at 10000 RPM, 10 Amps at 10,000 RPM |
| Emission Code | 3, 3, Off Road |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Height | 2.2 |
| Ignition Type | Performance |
| Length | 9.5 |
| Life Cycle Status Code | Available to Order |
| Maximum RPM | 14,000 |
| Mount Type | Surface Mount, Surface Mount |
| Mounting Hardware Included | Yes, Yes |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Control Module |
| Primary Voltage | 470, 470 Volts |
| Product Type | Ignition, Ignition |
| RPM | 14000 |
| RPM Range | 14,000 RPM with 14.4 Volts |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Voltage | 43000, 43,000 Volts |
| Series | Distributorless Ignitions |
| Spark Duration | 20 Degree Crankshaft Rotation |
| Spark Energy | 170 mJ per spark, 170 mJ/spark |
| Spark Energy (mJ per spark) | 170 |
| Spark Series Duration | 20 Degree Crankshaft Rotation, 20 Degree Crankshaft Rotation |
| Sub Category | Control Modules, Control Modules |
| Subcategory | Racing Electronics |
| Terminal Gender | Male Female |
| Terminal Quantity | 5 |
| Voltage | 10-18 V; Negative Ground |
| Voltage Required | 10-18 Volts, Negative Ground, 10-18 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight and Size | 3 lbs.,9.5"L x 4.5"W x 2.2"H, 3 lbs., 9.5L x 4.5W x 2.2H |
| Width | 4.5 |
| GTIN | 00085132621538 |
