Universal - Manual Boost-Referenced Timing Control
The 6 BTM is ideal for engines with a turbo or supercharger. Not only will the engine benefit from MSD's full power CD sparks, but there is also an adjustable boost/timing retard circuit to prevent detonation. When your turbo or blower forces the air/fuel mixture into the engine, the cylinder pressure inside the combustion chamber increases. The result is a great increase in power but this can also lead to detonation that can result in severe engine damage. The 6 BTM lets you dial away detonation by retarding the timing in relation to the boost pressure.
The 6 BTM is ideal for engines with a turbo or supercharger. Not only will the engine benefit from MSD's full power CD sparks, but there is also an adjustable boost/timing retard circuit to prevent detonation. When your turbo or blower forces the air/fuel mixture into the engine, the cylinder pressure inside the combustion chamber increases. The result is a great increase in power but this can also lead to detonation that can result in severe engine damage. The 6 BTM lets you dial away detonation by retarding the timing in relation to the boost pressure.
- Retard the ignition timing 1 degrees-3 degrees per pound of boost, maximum of 15 degrees, with dash mounted adjustable control knob
- Programmable for 4, 6, or 8-cylinders by cutting red/blue wire loops
- Accepts breaker points, amplifier and magnetic pickup trigger inputs
- Built-in Soft Touch Rev Control is adjustable with RPM Modules
- Supplied with rubber shock mounts
- Supplied with 3,000, 6,000, 7,000 & 8,000 RPM Module
- Works on 12 - 18 volt electrical system
- Multiple spark, capacitive discharge ignition control
- Multiple sparks for 20° of crankshaft rotation
- 110 millijoules per spark up to 15,000 RPM
- 470 primary voltage output to coil
- 12-15 Volts, 7 Volt Start
- CARB E.O. Approved
| Attributes | |
| ASIN | B00029JKBY |
| Brand | MSD, MSD |
| C.A.R.B. EO # | D-40-28 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Engine |
| Country of Origin (Primary) | US |
| Emission Code | 1, 1, Legal US |
| Features | Rev Limiter, Rev Limiter |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| part type | Engine Variable Valve Timing (VVT) Adjuster, Engine Variable Valve Timing (VVT) Adjuster |
| Primary Voltage | 520-540 Volts, 520-540 |
| Product Type | 6-BTM Boost Timing Master, 6-BTM Boost Timing Master |
| RPM | 15000 |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Series | 6-Series Ignitions |
| Sub Category | Hardware, Fasteners and Fittings, Hardware, Fasteners and Fittings |
| Subcategory | Ignition Boxes |
| Voltage Required | 12-15 Volts, 7 Volt Start, 12-15 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132064625 |
