Universal - Ignition Box and Laptop Required
The Power Grid Ignition System is the next evolution of our Programmable 7-Series Ignition Controls. The Grid incorporates an efficient 32 bit microcontroller and an all new software program, called MSD View, and is USB compatible. The Windows based software is designed with tabs to help racers easily select different programming windows and parameters. Also, the data acquisition files of the ignition are now captured on a micro SD card for ease of storage and reviewing.
The Power Grid Ignition System is the next evolution of our Programmable 7-Series Ignition Controls. The Grid incorporates an efficient 32 bit microcontroller and an all new software program, called MSD View, and is USB compatible. The Windows based software is designed with tabs to help racers easily select different programming windows and parameters. Also, the data acquisition files of the ignition are now captured on a micro SD card for ease of storage and reviewing.
- Five retard stages for nitrous
- .5 - .7 Amps
- Advanced individual cylinder timing based on gear or time
- Output switch set on rpm, pressure or time
- Four steps of rpm limits for burnout, spool, launch and overrev
- USB connection for ease of programming
- Timing based on engine rpm and gear value
- Shift light settings for each gear
- Crank Trigger system highly recommended
- Ignition data acquisition accepts multiple runs
Information:
Designed to be used with PN 7720 ignition controller. Can be used with MSD legacy ignition such as MSD 6, 7, 8 Series or a Pro Mag| Attributes | |
| ASIN | B00BZUAMYS |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Electrical |
| Country of Origin (Primary) | US |
| Current Draw | .5 - .7 Amps, .5 - .7 |
| Emission Code | 4, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Operating Voltage | 7-18 Volts, 7-18 |
| Product Type | Power Grid Controller, Power Grid Controller |
| Sale Category | Electrical |
| SDR Required Flag | N |
| Series | Power Grid Ignition Systems |
| Subcategory | Racing Electronics |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132077304 |
