Use with MSD 7 and 8 Series Ignitions ONLY - Short-Duration Applications
Sold Individually.
Sold Individually.
- For MSD 7 and 8 ignitions only, not for use on street vehicles
- Extremely low primary resistance
- Supplied with rubber shock mounts
- Housing is molded from a durable and high dielectric polyester
- High voltage coil designed for short duration applications only
- Primary and secondary windings are encased in Ciba polyurethane for vibration protection
| Attributes | |
| ASIN | B00029JKEG |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | CN |
| Emission Code | 4, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | 1 mH |
| Inductance (mH) | 1 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 43000, 43,000 Volts |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Coil |
| Peak Current | 800 mA, 800 |
| Primary Resistance | .030 ohms, .03 OHMs |
| Product Type | Ignition Coil, Ignition Coil |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Resistance | 240 ohms, 240 |
| Series | Pro Power Late Model Coils |
| Spark Duration | 180 uS, 0.18 |
| Sub Category | Ignition Coil |
| Subcategory | Coils and Parts |
| Turns Ratio | 100:1, 4.167361111111111 |
| Type | Drag Race / Short Duration Use, Drag Race / Short Duration Use |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132082018 |
