Designed exclusively for the HVC Professional Racing Ignition Control (#6631, #6632)
The HVC Coil is designed to be used exclusively with the MSD 6 HVC Series Ignition Controls (#6631, #6632). This Coil is not recommended for use with any other MSD Ignition Control or similar
The HVC Coil is designed to be used exclusively with the MSD 6 HVC Series Ignition Controls (#6631, #6632). This Coil is not recommended for use with any other MSD Ignition Control or similar
- Massive laminations and windings are engineered for less energy loss
- Delivers high voltage to ionize the plug gap while the spark glows with high current
- E-Core design produces more voltage and current while running 50% cooler than canister coils
Information:
The HVC Coil is designed to be used exclusively with the MSD 6 HVC Series Ignition Controls (#6631, #6632). This Coil is not recommended for use with any other MSD Ignition Control or similar aftermarket ignition.| Attributes | |
| ASIN | B00062ZCGE |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Black, Black |
| Country of Origin (Primary) | US |
| Emission Code | 4, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | 3 mH, 3mH |
| Inductance (mH) | 3 |
| Item Weight | 3.750 lbs. |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 34000, 34,000 Volts |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Coil |
| Peak Current | 600 mA, 600 |
| Primary Resistance | .070 ohms, .07 OHMs |
| Product Type | Ignition Coils, Ignition Coils |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Resistance | 360 ohms, 360 |
| Series | HVC and HVC II Coils |
| Spark Duration | 200 uS, 0.2 |
| Sub Category | Ignition Coil |
| Subcategory | Coils and Parts |
| Turns Ratio | 100:1, 4.167361111111111 |
| Type | Circle Track, Circle Track |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight | 3.75 Lbs, 3.75 |
| GTIN | 00085132082506 |
