Universal - Use with MSD 7 or 8 Series Ignition Control
The HVC II Coil is completely built in-house so our engineers have exclusive control over their performance and quality. The Coil utilizes an iron U-Core design with a segmented bobbin for improved voltage distribution. The bobbin is molded from Dupont Rynite FR946 material which has incredible dielectric capabilities at high temperatures. MSD also incorporated a cutting edge winding material that has an improved insulation and is also capable of enduring extreme voltages. Together, these materials create a durable coil with incredible voltage capabilities, lightning quick rise time and lengthy spark duration.
The HVC II Coil is completely built in-house so our engineers have exclusive control over their performance and quality. The Coil utilizes an iron U-Core design with a segmented bobbin for improved voltage distribution. The bobbin is molded from Dupont Rynite FR946 material which has incredible dielectric capabilities at high temperatures. MSD also incorporated a cutting edge winding material that has an improved insulation and is also capable of enduring extreme voltages. Together, these materials create a durable coil with incredible voltage capabilities, lightning quick rise time and lengthy spark duration.
- Windings are encased in fracture resistant compound for vibration resistance
- Designed for racing applications with an MSD 7 or 8 Series Ignition Control
- New U-core winding design produces more voltage and current
- Supplied with rubber shock mounts
- Dupont Rynite housing with isolated tower and brass primary terminals
- 70:1 turns ratio and lower primary resistance produce high voltage output
| Attributes | |
| ASIN | B0006302P4 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Emission Code | 4, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | .250 mH |
| Inductance (mH) | 0.25 |
| Item Weight | 3.750 lbs. |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 45000, 45,000 Volts |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Coil |
| Peak Current | 2 mA, 2 Amps |
| Primary Resistance | .016 ohms, 0.16 |
| Product Type | Coil, Coil |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Resistance | 30 ohms, 30 |
| Series | HVC and HVC II Coils |
| Spark Duration | 150 uS, 0.15 |
| Sub Category | Ignition Coil |
| Subcategory | Coils and Parts |
| Turns Ratio | 70:1, 2.917361111111111 |
| Type | Drag Race / Long Duration Use, Drag Race / Long Duration Use |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight | 3.75 lbs., 3.75 |
| GTIN | 00085132082612 |
