Use with MSD Power Grid 600 Single Channel - PN 8001
The HVC III Coil is completely built in-house so our engineers have exclusive control over their performance and quality. The Coil utilizes an iron U-Core design with a segmented bobbin for improved voltage distribution. The bobbin is molded from Dupont Rynite FR946 material which has incredible dielectric capabilities at high temperatures. MSD also incorporated a cutting-edge winding material that has improved insulation and is also capable of enduring extreme voltages. Together, these materials create a durable coil with incredible voltage capabilities, lightning-quick rise time, and longer spark duration. Equipped with an industry-first third terminal to allow secondary current sensing, for each spark, when used in conjunction with the MSD 8001 Pro 600 Single Channel ignition.
The HVC III Coil is completely built in-house so our engineers have exclusive control over their performance and quality. The Coil utilizes an iron U-Core design with a segmented bobbin for improved voltage distribution. The bobbin is molded from Dupont Rynite FR946 material which has incredible dielectric capabilities at high temperatures. MSD also incorporated a cutting-edge winding material that has improved insulation and is also capable of enduring extreme voltages. Together, these materials create a durable coil with incredible voltage capabilities, lightning-quick rise time, and longer spark duration. Equipped with an industry-first third terminal to allow secondary current sensing, for each spark, when used in conjunction with the MSD 8001 Pro 600 Single Channel ignition.
- Supplied with mounting hardware and rubber shock mounts
- Designed for racing applications with an MSD 7 or 8 Series Ignition Control or Pro 600 Single Channel - P/N 8001
- Windings are encased in fracture resistant compound for vibration resistance
- 70:1 turns ratio and lower primary resistant compound for vibration resistance
- Dupont Rynite housing with isolated tower and brass primary terminals
- New U-Core winding design produces more voltage and current
- Built-in Current Sensing when used with MSD Pro 600 Single Channel (8001)
Information:
**Designed to be used with Power Grid 600 Single Channel Ignition, PN 8001**| Attributes | |
| Brand | MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition |
| Color | Black, Black |
| Country of Origin (Primary) | US |
| Emission Code | 4, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | .250 mH |
| Inductance (mH) | 0.25 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 45,000 Volts, 45,000 |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Coil |
| Peak Current | 2 Amps, 2 |
| Primary Resistance | .016 OHMs, 0.016 |
| Product Type | Coil, Coil |
| SDR Required Flag | N |
| Secondary Resistance | 30 OHMs, 30 |
| Spark Duration | 150 uS, 0.15 |
| Sub Category | Ignition Coil |
| Turns Ratio | 70:1, 2.917361111111111 |
| Type | Drag Race / Long Duration Use, Drag Race / Long Duration Use |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Weight | 3.75 Lbs, 3.75 |
| GTIN | 00090127100677 |
