For racing, must be used with an MSD 6, 7 or 8-series ignition.
The Chevrolet housing has several racing features that racers will appreciate. At the base of the CNC machined housing there are two O-ring grooves. These seals prevent oil in the lifter gallery from leaking through the oil passage. If the engine deck, heads or intake have been modified, there is an adjustable slip collar which allows you to set the correct installation depth.
The Chevrolet housing has several racing features that racers will appreciate. At the base of the CNC machined housing there are two O-ring grooves. These seals prevent oil in the lifter gallery from leaking through the oil passage. If the engine deck, heads or intake have been modified, there is an adjustable slip collar which allows you to set the correct installation depth.
- 0.500” steel shaft is QPQ coated and guided by a sealed ball bearing and an extra long sintered bushing
- Mechanical advance assembly can be locked out for crank trigger systems
- Dual magnetic pickups are placed 180° apart to provide a complete redundant ignition system for racing applications
- Must be used with an MSD 6, 7, or 8-Series Ignition
- CNC machined billet aluminum housing and billet aluminum base
- Nylon pads ensure smooth operation of the advance weights
- O-ring seals can be installed for oil pressure control (modified blocks only)
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Advance weight pins are staked and tig welded to the plate
- Adjustable slip collar mounting flange for engines with modified deck heights
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Special oil tract improves lubrication to the distributor and cam gear
Application Summary:
| Year | Make/Model |
|---|---|
| 1955-1975 | Chevrolet Bel Air |
| 1981 | Chevrolet Bel Air |
| 1958-1972 | Chevrolet Biscayne |
| 1969-1974 | Chevrolet Blazer |
| 1987-1994 | Chevrolet Blazer |
| 1958-1961 | Chevrolet Brookwood |
| 1969-1972 | Chevrolet Brookwood |
| 1975-1986 | Chevrolet C10 |
| 1960-1974 | Chevrolet C10 Pickup |
| 1967-1986 | Chevrolet C10 Suburban |
| 1982-1985 | Chevrolet C15 |
| 1988-1999 | Chevrolet C1500 |
| 1992-1999 | Chevrolet C1500 Suburban |
| 1975-1987 | Chevrolet C20 |
| 1960-1974 | Chevrolet C20 Pickup |
| 1967-1986 | Chevrolet C20 Suburban |
| 1988-2000 | Chevrolet C2500 |
| 1992-1999 | Chevrolet C2500 Suburban |
| 1975-1986 | Chevrolet C30 |
| 1966 | Chevrolet C30 Panel |
| 1960-1974 | Chevrolet C30 Pickup |
| 1983-2000 | Chevrolet C35 |
| 1988-2000 | Chevrolet C3500 |
| 1960-1962 | Chevrolet C40 |
| 1967-1992 | Chevrolet Camaro |
| 1966-1996 | Chevrolet Caprice |
| 1964-1973 | Chevrolet Chevelle |
| 1963-1968 | Chevrolet Chevy II |
| 1955-1982 | Chevrolet Corvette |
| 1984-1996 | Chevrolet Corvette |
| 1957-1958 | Chevrolet Del Ray |
| 1959-1960 | Chevrolet El Camino |
| 1964-1987 | Chevrolet El Camino |
| 1969-1970 | Chevrolet Estate |
| 1996-2002 | Chevrolet Express 1500 |
| 1996-2002 | Chevrolet Express 2500 |
| 1996-2002 | Chevrolet Express 3500 |
| 1975-1995 | Chevrolet G10 |
| 1968-1974 | Chevrolet G10 Van |
| 1975-1995 | Chevrolet G20 |
| 1967-1974 | Chevrolet G20 Van |
| 1975-1996 | Chevrolet G30 |
| 1970-1974 | Chevrolet G30 Van |
| 1958-1985 | Chevrolet Impala |
| 1994-1996 | Chevrolet Impala |
| 1975-1986 | Chevrolet K10 |
| 1960-1974 | Chevrolet K10 Pickup |
| 1967-1986 | Chevrolet K10 Suburban |
| 1988-1999 | Chevrolet K1500 |
| 1992-1999 | Chevrolet K1500 Suburban |
| 1975-1986 | Chevrolet K20 |
| 1967 | Chevrolet K20 Panel |
| 1960-1974 | Chevrolet K20 Pickup |
| 1967-1986 | Chevrolet K20 Suburban |
| 1988-2000 | Chevrolet K2500 |
| 1992-1999 | Chevrolet K2500 Suburban |
| 1977-1986 | Chevrolet K30 |
| 1968-1974 | Chevrolet K30 Pickup |
| 1988-2000 | Chevrolet K3500 |
| 1975-1986 | Chevrolet K5 Blazer |
| 1959-1961 | Chevrolet Kingswood |
| 1969-1972 | Chevrolet Kingswood |
| 1973-1976 | Chevrolet Laguna |
| 1964-1967 | Chevrolet Malibu |
| 1973-1983 | Chevrolet Malibu |
| 1970-1988 | Chevrolet Monte Carlo |
| 1976-1979 | Chevrolet Monza |
| 1955-1961 | Chevrolet Nomad |
| Attributes | |
| ASIN | B000COUPBS |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | Dual Point, Magnetic Pickup |
| Emission Code | 4, 4, Off Road |
| Engine Make/Size | Chevy Big Block (396-454), Chevy Small Block (262-400) |
| Gear Material | Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| part type | Distributor, Distributor |
| Product Type | Distributor, Distributor |
| SDR Required Flag | N |
| Series | Pro Billet Distributors |
| Sub Category | Distributor and Magneto, Distributor and Magneto |
| Subcategory | Distributors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132083565 |
