Drop-in replacement distributor- Black for Late Model GM HEI distributors with exterior coil.
The entire housing is CNC-machined to exact tolerances for incredible strength (not to mention cool looks). For improved lubrication there is an extra oil tract machined into the bottom of the housing that delivers oil directly to the cam and distributor gears. Inside, a polished steel shaft receives guidance from a sealed ball bearing and an extra-long sintered bushing adds stability. This 0.500" shaft also receives a QPQ coating for increased friction reduction and corrosion resistance.
- CNC machined billet aluminum housing and billet aluminum base
- Special oil tract improves lubrication to the distributor and cam gear
- Oversized steel shaft is QPQ coated and guided by a sealed ball bearing and an extra long sintered bushing
- Drop-in billet replacement for GM distributors with the small cap and external coil
- O-ring seals can be added to modified blocks to improve oil pressure control
- Legal to install in all 50 states
- Marine UL Certified
- Magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Supplied with late model distributor cap and rotor
- Factory style ignition module accepts factory wiring
Application Summary:
| Year |
Make/Model |
| 1990-1993 |
Chevrolet C1500 |
| 1991-1995 |
Chevrolet C2500 |
| 1988-1995 |
Chevrolet C3500 |
| 1991-1995 |
Chevrolet K2500 |
| 1988-1995 |
Chevrolet K3500 |
| 1987-1988 |
Chevrolet R20 |
| 1989 |
Chevrolet R2500 |
| 1987-1988 |
Chevrolet R30 |
| 1989-1991 |
Chevrolet R3500 |
| 1987-1988 |
Chevrolet V30 |
| 1989-1991 |
Chevrolet V3500 |
| 1992-1995 |
GMC C2500 |
| 1988-1995 |
GMC C3500 |
| 1991-1995 |
GMC K2500 |
| 1988-1995 |
GMC K3500 |
| 1987-1989 |
GMC R2500 |
| 1987-1991 |
GMC R3500 |
| 1987-1991 |
GMC V3500 |
| Attributes |
| ASIN |
B0711HYTPP |
| Brand |
MSD, MSD |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category |
Ignition, Ignition |
| Color |
Black, Black |
| Country of Origin (Primary) |
US |
| Distributor Cap Included |
Yes |
| Distributor Type |
Magneto, OE Replacement |
| Emission Code |
2, 2 |
| Engine Make/Size |
Chevy V8 |
| Gear Material |
Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8511804000 |
| Hazardous Material Code |
N |
| Ignition Box Required |
No |
| Ignition Coil Included |
No |
| Ignition Rotor Included |
Yes |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| part type |
Distributor, Distributor |
| Product Type |
Distributor, Distributor |
| SDR Required Flag |
N |
| Series |
Pro Billet Distributors |
| Sub Category |
Distributor and Magneto, Distributor and Magneto |
| Subcategory |
Distributors |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time |
12 |
| GTIN |
00085132836635 |
