For 194, 230, 250, 292 Inline-6 engines. Must be used with an MSD 6, 7 or 8-series ignition.
Starting on the inside, a 0.500" oversized steel shaft spins in a sealed ball bearing and sintered bushing for long endurance and accurate spark delivery throughout the entire rpm range. Mounted on top of the shaft is an easy-to-adjust chromoly mechanical advance assembly. Different advance springs and stop bushings are supplied so you can choose from a variety of curves.
Starting on the inside, a 0.500" oversized steel shaft spins in a sealed ball bearing and sintered bushing for long endurance and accurate spark delivery throughout the entire rpm range. Mounted on top of the shaft is an easy-to-adjust chromoly mechanical advance assembly. Different advance springs and stop bushings are supplied so you can choose from a variety of curves.
- Designed for street/performance use with a mechanical and vacuum advance
- Mechanical advance assembly can be locked out for crank trigger systems
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Advance weight pins are staked and tig welded to the plate
- O-ring seals can be added to modified blocks to improve oil pressure control
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Will not fit 235 and 261 engines
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Vacuum advance canister for improved economy (can be locked out)
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing
- Special oil tract improves lubrication to the distributor and cam gear
- CARB E.O. Approved
- Nylon pads ensure smooth operation of the advance weights
- Supplied with a socket style distributor cap and rotor
- CNC machined billet aluminum housing and billet aluminum base
- Must be used with an MSD Ignition Control
Application Summary:
| Year | Make/Model |
|---|---|
| 1961-1973 | Chevrolet Bel Air |
| 1961-1972 | Chevrolet Biscayne |
| 1969-1974 | Chevrolet Blazer |
| 1969 | Chevrolet Brookwood |
| 1961-1974 | Chevrolet C10 Pickup |
| 1967-1974 | Chevrolet C10 Suburban |
| 1961-1974 | Chevrolet C20 Pickup |
| 1968-1974 | Chevrolet C20 Suburban |
| 1961-1974 | Chevrolet C30 Pickup |
| 1967-1974 | Chevrolet Camaro |
| 1967-1969 | Chevrolet Caprice |
| 1964-1974 | Chevrolet Chevelle |
| 1962-1968 | Chevrolet Chevy II |
| 1964-1974 | Chevrolet El Camino |
| 1964-1974 | Chevrolet G10 Van |
| 1967-1974 | Chevrolet G20 Van |
| 1970-1974 | Chevrolet G30 Van |
| 1961-1973 | Chevrolet Impala |
| 1961-1962 | Chevrolet K10 Pickup |
| 1964-1974 | Chevrolet K10 Pickup |
| 1968-1974 | Chevrolet K10 Suburban |
| 1961-1962 | Chevrolet K20 Pickup |
| 1964-1974 | Chevrolet K20 Pickup |
| 1968-1974 | Chevrolet K20 Suburban |
| 1968-1974 | Chevrolet K30 Pickup |
| 1969-1974 | Chevrolet Nova |
| 1961-1966 | Chevrolet Suburban |
| 1964-1965 | GMC 1000 Series |
| 1964-1965 | GMC 1500 Series |
| 1975-1976 | GMC C15 |
| 1967-1974 | GMC C15/C1500 Pickup |
| 1967-1971 | GMC C15/C1500 Suburban |
| 1974 | GMC C15/C1500 Suburban |
| 1975 | GMC C25 |
| 1967-1974 | GMC C25/C2500 Pickup |
| 1967-1972 | GMC C25/C2500 Suburban |
| 1974 | GMC C25/C2500 Suburban |
| 1975 | GMC C35 |
| 1967-1974 | GMC C35/C3500 Pickup |
| 1975-1976 | GMC G15 |
| 1967-1974 | GMC G15/G1500 Van |
| 1967-1974 | GMC G25/G2500 Van |
| 1971 | GMC G35/G3500 Van |
| 1974 | GMC G35/G3500 Van |
| 1970 | GMC Jimmy |
| 1973 | GMC Jimmy |
| 1975-1976 | GMC K15 |
| 1967-1974 | GMC K15/K1500 Pickup |
| 1967-1971 | GMC K15/K1500 Suburban |
| 1975-1976 | GMC K25 |
| 1967-1974 | GMC K25/K2500 Pickup |
| 1968-1972 | GMC K25/K2500 Suburban |
| 1968-1972 | GMC K35/K3500 Pickup |
| 1974 | GMC K35/K3500 Pickup |
| 1971-1972 | GMC Sprint |
| 1975-1976 | GMC Sprint |
| 1963-1966 | GMC Suburban |
| Attributes | |
| ASIN | B000ECFD3S |
| Brand | MSD, MSD |
| C.A.R.B. EO # | D-40-39 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | HEI/Breakerless, Magnetic Pickup |
| Emission Code | 1, 1, Legal US |
| Engine Make/Size | Chevy 194-292 |
| Gear Material | Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| part type | Distributor, Distributor |
| Product Type | Distributor, Distributor |
| SDR Required Flag | N |
| Series | Pro Billet Distributors |
| Sub Category | Distributor and Magneto, Distributor and Magneto |
| Subcategory | Distributors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132085156 |
