Fits big block Chevy. Must be used with a Jesel or Comp Cams Camshaft Belt Drive Kit and an MSD Flying Magnet Crank Trigger.
The MSD Front Drive distributor is belt-driven from a pulley installed on the camshaft. For increased strength and durability a 9mm belt is used which is wider than any other drive assembly. The distributor head is CNC-machined from a billet of aluminum and is secured to a strong precision bracket. This system is an extremely accurate way to distribute the spark energy from your MSD Ignition!
The MSD Front Drive distributor is belt-driven from a pulley installed on the camshaft. For increased strength and durability a 9mm belt is used which is wider than any other drive assembly. The distributor head is CNC-machined from a billet of aluminum and is secured to a strong precision bracket. This system is an extremely accurate way to distribute the spark energy from your MSD Ignition!
- Band clamp mount allows easy rotor phasing adjustment
- The only front drive distributor with adjustable belt tension
- The MSD Cap and Rotor are injection molded from strong DuPont Rynite material
- Supplied with cam gear, hardware and extra wide 9mm belt
- Billet aluminum bracket and lower housing for strength
Information:
Will not fit raised cam big blocks such as Merlin, Donovan or Dart blocks or GEN V or GEN VI **Optional Bolt Down Clamp Kit, PN 8499**| Attributes | |
| ASIN | B001PRUGOW |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | Front Drive, Crank Trigger |
| Emission Code | 4, 4, Off Road |
| Engine Make/Size | Chevy Big Block (396-502) |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| part type | Distributor, Distributor |
| Product Type | Distributor, Distributor |
| Qty | 1 |
| Quantity | 1 |
| SDR Required Flag | N |
| Series | Pro Billet Distributors |
| Sub Category | Distributor and Magneto, Distributor and Magneto |
| Subcategory | Distributors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132085200 |
