All the performance of our Pro-Billet line NOW available with Black cap for your small block Chrysler. Must be used with MSD 6, 7, or 8-series ignition.
Supporting the advance assembly is a hardened, polished steel shaft. Two ball bearing guides are used to support the shaft producing incredible stability. Precision paddles of a zinc-plated reluctor pass a maintenance-free magnetic pickup creating a trigger signal that tells the MSD to fire.
Supporting the advance assembly is a hardened, polished steel shaft. Two ball bearing guides are used to support the shaft producing incredible stability. Precision paddles of a zinc-plated reluctor pass a maintenance-free magnetic pickup creating a trigger signal that tells the MSD to fire.
- Advance weight pins are staked and tig welded to the plate
- Supplied with black cap w/316 stainless steel terminals
- Nylon pads ensure smooth operation of the advance weights
- Easy-to-adjust mechanical advance with supplied springs and stop bushings (except locked out versions)
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing for smooth operation at all rpms
- Mechanical advance assembly can be locked out for crank trigger systems or racing applications
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Must be used with an MSD Ignition Control
- CNC machined billet aluminum housing and billet aluminum base providing superior strength and great looks
Information:
Must be used with an MSD 6, 7 or 8 Series Ignition.Application Summary:
| Year | Make/Model |
|---|---|
| 1975-1983 | Chrysler Cordoba |
| 1983-1989 | Chrysler Fifth Avenue |
| 1981-1983 | Chrysler Imperial |
| 1977-1982 | Chrysler LeBaron |
| 1977-1982 | Chrysler New Yorker |
| 1971-1981 | Chrysler Newport |
| 1978-1981 | Chrysler Town & Country |
| 1976-1980 | Chrysler Valiant |
| 1964 | Dodge 330 |
| 1964-1966 | Dodge A100 |
| 1970 | Dodge A100 |
| 1964-1970 | Dodge A100 Truck |
| 1976-1980 | Dodge Aspen |
| 1975-1980 | Dodge B100 |
| 1971-1974 | Dodge B100 Van |
| 1981-1994 | Dodge B150 |
| 1995-1998 | Dodge B1500 |
| 1975-1980 | Dodge B200 |
| 1971-1974 | Dodge B200 Van |
| 1981-1994 | Dodge B250 |
| 1995-1998 | Dodge B2500 |
| 1975-1980 | Dodge B300 |
| 1971-1974 | Dodge B300 Van |
| 1981-1994 | Dodge B350 |
| 1995-1998 | Dodge B3500 |
| 1973-1980 | Dodge CB300 |
| 1970-1974 | Dodge Challenger |
| 1967-1978 | Dodge Charger |
| 1965-1976 | Dodge Coronet |
| 1975-1980 | Dodge D100 |
| 1984-1989 | Dodge D100 |
| 1976-1977 | Dodge D100 Panel |
| 1979-1980 | Dodge D100 Panel |
| 1968-1974 | Dodge D100 Pickup |
| 1967 | Dodge D100 Series |
| 1977-1993 | Dodge D150 |
| 1975-1980 | Dodge D200 |
| 1968-1974 | Dodge D200 Pickup |
| 1967 | Dodge D200 Series |
| 1981-1993 | Dodge D250 |
| 1975-1980 | Dodge D300 |
| 1968-1974 | Dodge D300 Pickup |
| 1967 | Dodge D300 Series |
| 1981-1993 | Dodge D350 |
| 1989-2003 | Dodge Dakota |
| 1964-1977 | Dodge Dart |
| 1980-1982 | Dodge Dart |
| 1977-1989 | Dodge Diplomat |
| 1989-1992 | Dodge DM350 |
| 1998-2003 | Dodge Durango |
| 1968-1974 | Dodge M300 |
| 1974 | Dodge M350 |
| 1978-1979 | Dodge Magnum |
| 1981-1982 | Dodge Magnum |
| 1970-1974 | Dodge MB300 |
| 1980-1983 | Dodge Mirada |
| 1968-1978 | Dodge Monaco |
| 1966-1973 | Dodge Polara |
| 1972-1974 | Dodge R300 |
| 1994-2003 | Dodge Ram 1500 |
| 1995-1996 | Dodge Ram 1500 Van |
| 1998-2003 | Dodge Ram 1500 Van |
| 1994-2002 | Dodge Ram 2500 |
| 1997-2003 | Dodge Ram 2500 Van |
| 1994-2002 | Dodge Ram 3500 |
| 1997-2003 | Dodge Ram 3500 Van |
| 1974-1996 | Dodge Ramcharger |
| 1999-2001 | Dodge Ramcharger |
| 1978-1980 | Dodge RD200 |
| 1973-1974 | Dodge RM300 |
| 1975-1977 | Dodge Royal Monaco |
| 1979-1981 | Dodge St. Regis |
| 1975-1977 | Dodge W100 |
| 1984-1989 | Dodge W100 |
| 1968-1974 | Dodge W100 Pickup |
| 1967 | Dodge W100 Series |
| 1977-1993 | Dodge W150 |
| 1975-1980 | Dodge W200 |
| 1968-1974 | Dodge W200 Pickup |
| 1967 | Dodge W200 Series |
| Attributes | |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Black, Black |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | Race, Magnetic Pickup |
| Emission Code | 3, 3, Off Road |
| Engine | Chrysler Small Block 318-360 |
| Engine Make/Size | Mopar 318, Mopar 360 |
| Gear | N/A |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes, Yes |
| Ignition Coil Included | No, No |
| Ignition Rotor Included | Yes, Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Product Type | Distributor, Distributor |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Series | Pro Billet Distributors |
| Subcategory | Distributors |
| Type | MSD Box required, MSD Box required |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132853458 |
