Nearly three inches of adjustment. Must be used with an MSD 6, 7 or 8-series ignition.
The distributor shares the same features of the standard Pro-Billet Chevrolet model including a ball bearing guide, long sintered lower bushing and an oil seal. To trigger the MSD Ignition a maintenance-free magnetic pick-up is secured in the billet base of the distributor. Just above this pick-up assembly is an adjustable mechanical advance assembly.
The distributor shares the same features of the standard Pro-Billet Chevrolet model including a ball bearing guide, long sintered lower bushing and an oil seal. To trigger the MSD Ignition a maintenance-free magnetic pick-up is secured in the billet base of the distributor. Just above this pick-up assembly is an adjustable mechanical advance assembly.
- O-ring seals can be added to modified blocks to improve oil pressure control
- Must be used with an MSD Ignition Control
- Nylon pads ensure smooth operation of the advance weights
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Mechanical advance assembly can be locked out for crank trigger systems
- CNC machined billet aluminum housing and Dupont Rynite base
- No CARB Exemption Order Number
- Extra tall housing is designed for use with Alan Root, Donovan, Merlin and Rocket racing blocks
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing and long sintered bushing
- Special oil tract improves lubrication to the distributor and cam gear
- Adjustable slip collar mounting flange provides up to 3” of adjustment
- Advance weight pins are staked and tig welded to the plate
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Supplied with an HEI style distributor cap and rotor (accepts Cap-A-Dapts)
| Attributes | |
| ASIN | B000ECJJ4M |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | HEI/Breakerless, Magnetic Pickup |
| Emission Code | 3, 3, Off Road |
| Engine Make/Size | Chevy Big Block (396-454), Chevy Small Block (262-400) |
| Gear Material | Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| part type | Distributor, Distributor |
| Product Type | Distributor, Distributor |
| SDR Required Flag | N |
| Series | Pro Billet Distributors |
| Sub Category | Distributor and Magneto, Distributor and Magneto |
| Subcategory | Distributors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132085477 |
