Alcohol compatible
Billet Bypass Regulator W/JET - Designed for use with a mechanical fuel pump where fuel pressure is variable. By-Pass feature is restricted with a jet that can be adjusted to set your desired low-side fuel pressure. Blue anodized top has a fitting for boost referenced applications, comes with laser cut stainless mounting bracket and hardware. #8 AN O-Ring fittings required.
Billet Bypass Regulator W/JET - Designed for use with a mechanical fuel pump where fuel pressure is variable. By-Pass feature is restricted with a jet that can be adjusted to set your desired low-side fuel pressure. Blue anodized top has a fitting for boost referenced applications, comes with laser cut stainless mounting bracket and hardware. #8 AN O-Ring fittings required.
- Designed to operate within 4.5 - 9 PSI; Preset at 7 PSI
- .350" (7/20") restriction
- Designed for use with alcohol fuel
- Compatible with QFT™ billet fuel pressure regulator logs
- Boost Reference 1-1
- Includes an 1/8" NPT port for manifold reference
| Attributes | |
| Adjustable | Yes |
| Alternate Part Number | 30-1899 |
| ASIN | B00C3VU5RC |
| Brand | Quick Fuel, Quick Fuel Technology |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Air and Fuel Delivery |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| Fuel Type | Gasoline, Gasoline |
| Gauge Included | No |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Inlet Type | 8 AN ORB |
| Life Cycle Status Code | Available to Order |
| Maximum Pressure | 9 |
| Minimum Pressure | 4.5 |
| Mounting Bracket Included | Yes |
| NAFTA Preference Criterion Code | B |
| Outlet Type | 8 AN ORB |
| part type | Fuel Pressure Regulator |
| Product Type | Regulator, Fuel Pressure Regulator |
| SDR Required Flag | N |
| Sub Category | Carburetion |
| Vacuum Port Quantity | 1 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00849804006890 |
