2-Port Fuel Pressure Regulator
2-Port Regulator designed to provide smooth, consistent and repeatable performance. This regulator is machined from aircraft garde billet aluminum and anodized for added durability and reliable performance.
2-Port Regulator designed to provide smooth, consistent and repeatable performance. This regulator is machined from aircraft garde billet aluminum and anodized for added durability and reliable performance.
- •Hard-coat anodized billet housing.
- •Supports engines up to 650 HP.
- •#10 AN inlet and #8 AN outlet ports.
- •Adjustable from 5-8 PSI.
- •Fluorocarbon diaphragms and Viton® O-rings.
- •Stainless steel pins, brass valve guides, and hard-coat anodized diaphragm plates.
- •Compatible for use with all fuels.
- •Serviced by using 30-7303 Rebuild Kit.
| Attributes | |
| Adjustable | Yes |
| Alternate Part Number | 30-7025 |
| ASIN | B00YJHCUBM |
| Brand | Quick Fuel, Quick Fuel Technology |
| California Proposition 65 | No |
| Category | Air and Fuel Delivery |
| Color | Black and Red, Black / Red |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| Fuel Type | Gasoline, Gasoline |
| Gauge Included | No |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Inlet Type | 10 AN ORB |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum, Aluminum |
| Maximum Pressure | 8 |
| Minimum Pressure | 5 |
| Mounting Bracket Included | Yes |
| NAFTA Preference Criterion Code | B |
| Outlet Port Quantity | 2 |
| Outlet Type | 8 AN ORB |
| part type | Fuel Pressure Regulator |
| Product Type | Regulator, Fuel Pressure Regulator |
| SDR Required Flag | N |
| Sub Category | Carburetion |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00849804014680 |
