Low Pressure Regulator
Pressure regulator with ball and stem activation and GFLT diaphragm. Designed for methanol fuel.
Pressure regulator with ball and stem activation and GFLT diaphragm. Designed for methanol fuel.
- •Supports up to 600 HP engines
- •Black anodized housing
- •Adjustable from 4.5 - 9 PSI; Preset to 6.5 PSI
- •3/8" NPT Ports
- •.250" (1/4") restriction
- •Includes mounting bracket
- •Includes an 1/8" NPT port for manifold reference
- Boost Reference 1-1
| Attributes | |
| Adjustable | Yes |
| Alternate Part Number | 30-805 |
| ASIN | B00CF7BLMC |
| Brand | Quick Fuel, Quick Fuel Technology |
| California Proposition 65 | No |
| Category | Air and Fuel Delivery |
| Color | Black, Black |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| Fuel Type | Gasoline, Gasoline |
| Gauge Included | No |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Inlet Gender | Female |
| Inlet Port Diameter | 3/8, 3/8 |
| Inlet Port Quantity | 1 |
| Inlet Type | NPT |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum, Aluminum |
| Maximum Pressure | 9 |
| Minimum Pressure | 4.5 |
| Mounting Bracket Included | Yes |
| NAFTA Preference Criterion Code | B |
| Outlet Gender | Female |
| Outlet Port Diameter | 3/8, 3/8 |
| Outlet Port Quantity | 2 |
| Outlet Type | NPT |
| part type | Fuel Pressure Regulator |
| Product Type | Regulator, Fuel Pressure Regulator |
| Sale Category | Air and Fuel Delivery |
| SDR Required Flag | N |
| Sub Category | Carburetion |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00849804006982 |
