The IQ3 Drag Bracket bundle combines our popular IQ3 Drag Logger Dash with the most common V-Net sensors and a cable.

---

The full feature dash bundle kit includes the ability to monitor Engine RPM, Driveshaft RPM, Trans Brake Release, Water Temp, Oil Press, Carb Fuel Press, and Trans Temp. All external sensor data is routed to the rear of the dash by a single V-Net cable and main wiring harness. The datalink II software included with IQ3 Drag dash provides professional-level data analysis capabilities, but in an easy to learn format.

• Channels: 12 Total - 6 V-Net digital/analog - 6 internal
• Displays up to 28 inputs via 4 pages of microSD Memory.
• Blue Backlight for a stylish look.
• Gear Indicator
• Eight user definable alarms with on screen warning text and lights
• User defined 5 character sensor input names
• User defined shift points
• Shielded, low glare display for sunlight viewing
• Metric and English units for multiple display options.
• Compatible with many aftermarket EFI ECU systems.
• Bundle Kit includes V-Net Module and sensor for Carb Press and Trans Temp
• Sample Rate: V-Net records data up to 100 frames per second
• Memory: up to 16GB MicroSD card
• 6 external V-Net sensor inputs are available along with an optional high speed logging modules for shock travels

---

Information:

Compatible ECU systems include the following: AEM V2/EMS-4/Infinity EMS Big Stuff 3 Electromotive TECGT EMS EM-Tech ECU Emtron ECU FAST XFI Fuel Tech (200,250,300,350,500v1,500v2, 600) Holley Dominator InjPro Life Racing F88 Link G4+ Series MaxxECU MEFI-4B MegaSquirt-III (DIY Autotune) MicroTech MoTeC CAN (Data set 3) MSD Atomic LS MSD Atomic TBI OBD-II (2008 and later) Pro EFI User Configured (CAN bus knowledge required)
