The Sportsman data acquisition system is designed to meet all of the needs of the sportsman drag racer, including their budget. This compact recorder provides up to 25 channels of data. Comes with DataLink Software.
Drive Shaft RPM (Requires Driveshaft Collar Sold Separately)
Drive Shaft RPM (Requires Driveshaft Collar Sold Separately)
- Channels: 25 Total - 7 Internal - 8 EGT channels (Sensors sold separate), and 4 shock channels (Sensors sold separate). 6 V-Net (Expandable)
- Sample Rate: up to 100 frames per second, to capture every channel for in-depth analysis.
- Memory: included SD Card, for quick and easy file transfer to a computer.
- Internal Sensors: Engine RPM, Driveshaft RPM, Battery Voltage, Start Record Button, 2 Axis G Meter, 12 Volt Event
- Weight: .65 lbs
Information:
Sportsman loggers DO NOT INCLUDE a drive shaft collar.| Attributes | |
| Application | Drag Racing |
| Brand | Racepak |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Gauges and Gauge Accessories |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| Emission Code Description | Part does not affect Vehicle Emissions |
| Harmonized Tariff Code (Schedule B) | 8471900000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Model | 610-KT-SPRTMN, 610-KT-SPRTMN |
| NAFTA Preference Criterion Code | B |
| Operating Voltage | 12-18 volts, 12-18 volts |
| Product Type | Data Loggers, Data Loggers |
| Sale Category | Gauges and Gauge Accessories |
| SDR Required Flag | N |
| Start Record Method | Momentary Button, Momentary Button |
| Upgrades | 4 Ch Upgrade 610-UG-SPRT4 |
| Warning | California Proposition 65, California Proposition 65 |
| GTIN | 00815046024909 |
